Secop hermetic compressors not only have low energy consumption for optimized running costs. They are also very compact and provide good acoustic performance to ensure the best possible end-user convenience.
Other features and benefits include:
Secop's continuous commitment to new intelligent LC solutions has over 45 years of experience, translated into close partnerships with suppliers and customers all over the world.
Our three focus application areas for LC use are: glass door merchandise, stainless steel and food retail refrigerated and freezing cabinets.
Series | Model | Horse Power | Disp. | Capacity | Voltage | Refrigerant | Back Pressure |
(HP) | (cc) | (-23.3℃) | |||||
FR | FR6CL | 1/6 | 6.23 | 307W | 220-240V 50HZ | R404a | LBP/MBP |
FR | FR8.5CL | 1/4 | 7.95 | 366W | 220-240V 50HZ | R404a | LBP/MBP |
NL | NF7CLX | 1/3 | 7.24 | 426W | 220-240V 50HZ | R404a | LBP/MBP |
NL | NL8.4CLX | 1/4 | 8.35 | 471W | 220-240V 50HZ | R404a | LBP/MBP |
NL | NL9CLX | 1/3 | 9 | 457W | 220-240V 50HZ | R404a | LBP/MBP |
SC | SC10CL | 1/3 | 10.29 | 470W | 220-240V 50HZ | R404a | LBP/MBP |
SC | SC10CLX | 1/3 | 10.29 | 474W | 220-240V 50HZ/60HZ | R404a | LBP/MBP |
SC | SC12CL | 3/8 | 12.87 | 625W | 220-240V 50HZ | R404a | LBP/MBP |
SC | SC12CLX.2 | 1/2 | 12.87 | 670W | 220-240V 50HZ/60HZ | R404a | LBP/MBP |
SC | SC15CL | 1/2 | 15.28 | 777W | 220-240V 50HZ | R404a | LBP/MBP |
SC | SC15CLX.2 | 1/2 | 15.28 | 805W | 220-240V 50HZ | R404a | LBP/MBP |
SC | SC18CL | 5/8 | 17.69 | 901W | 220-240V 50HZ | R404a | LBP/MBP |
SC | SC18CLX.2 | 3/4 | 17.69 | 986W | 220-240V 50HZ | R404a | LBP/MBP |
SC | SC21CL | 7/8 | 21 | 1033W | 220-240V 50HZ | R404a | LBP/MBP |
GS | GS26CLX | 1 | 26.3 | 1270W | 208-230V 60HZ | R404a | LBP/MBP |
GS | GS26CLX | 1 | 26.3 | 1270W | 220-240V 50HZ | R404a | LBP/MBP |
GS | GS34CLX | 1 1/4 | 33.8 | 1754W | 220-240V 50HZ | R404a | LBP/MBP |
NL | NL6.1MLX | 1/6 | 6.13 | 425W | 220-240V 50/60HZ | R404a | MBP/HBP |
NL | NF7MLX | 1/5 | 7.27 | 466W | 220-240V 50/60HZ | R404a | MBP/HBP |
SC | SC10MLX | 1/2 | 10.29 | 615W | 220-240V 50/60HZ | R404a | MBP/HBP |
SC | SC12MLX | 5/8 | 12.87 | 754W | 220-240V 50/60HZ | R404a | MBP/HBP |
SC | SC15MLX | 3/4 | 15.28 | 951W | 220-240V 50HZ | R404a | MBP/HBP |
SC | SC18MLX | 7/8 | 17.69 | 1110W | 220-240V 50HZ | R404a | MBP/HBP |
SC | SC18MLX.3 | 7/8 | 17.7 | 1386W | 220-240V 50HZ | R404a | MBP/HBP |
GS | GS26MLX | 1 1/4 | 26.3 | 1991W | 220-240V 50HZ | R404a | MBP/HBP |
GS | GS34MLX | 1 1/2 | 33.8 | 2649W | 220-240V 50HZ | R404a | MBP/HBP |
SC | SC10DL | 1/2 | 10.29 | 710W | 220-240V 50HZ | R404a | HBP |
SC | SC12DL | 3/4 | 12.87 | 937W | 220-240V 50HZ | R404a | HBP |
SC | SC15DL | 1 | 15.28 | 1121W | 220-240V 50HZ | R404a | HBP |
SC | SC10D | 3/8 | 10.28 | 565W | 220-240V 50HZ | R22 | MBP/HBP |
SC | SC12D | 1/2 | 12.87 | 720W | 220-240V 50HZ | R22 | MBP/HBP |
SC | SC15D | 3/4 | 15.28 | 890W | 220-240V 50HZ | R22 | MBP/HBP |
SC | SC10C | 3/8 | 10.29 | 395W | 220-240V 50HZ | R22 | LBP/MBP |
SC | SC15CM | 3/4 | 15.28 | 620W | 220-240V 50HZ | R22 | LBP/MBP |
SC | SC18CM | 1 | 17.69 | 710W | 220-240V 50HZ | R22 | LBP/MBP |
SC | SC10G | 1/3 | 10.29 | 166W | 220V-240V 50Hz | R134a | LBP/HBP/MBP |
SC | SC12G | 1/3 | 12.87 | 246W | 220V-240V 50Hz | R134a | LBP/HBP/MBP |
SC | SC15G | 3/8 | 15.28 | 255W | 220V-240V 50Hz | R134a | LBP/HBP/MBP |
SC | SC18G | 1/2 | 17.69 | 392W | 220V-240V 50Hz | R134a | LBP/HBP/MBP |
SC | SC21G | 5/8 | 20.95 | 456W | 220V-240V 50Hz | R134a | LBP/HBP/MBP |
SC | SC15GH | 3/8 | 15 | 281W | 220V-240V 50Hz | R134a | MBP/HBP |
SC | SC10GH | 1/3 | 10 | 250W | 220V-240V 50Hz | R134a | MBP/HBP |
TL | TL5G | 5.08 | 172W | 220V-240V 50Hz | R134a | LBP/HBP/MBP | |
NL | NL8.4MF | 1/4 | 8.35 | 359W | 220-240V 50/60HZ | R134a | MBP/HBP |
NL | NL10MF | 1/3 | 10.1 | 382W | 220-240V 50/60HZ | R134a | MBP/HBP |
NL | NL11MF | 1/3 | 11.15 | 418W | 220-240V 50HZ | R134a | MBP/HBP |
SC | SC15MFX | 3/8 | 15.28 | 483W | 220-240V 50HZ | R134a | MBP/HBP |
SC | SC21MFX | 5/8 | 20.95 | 750W | 220-240V 50HZ | R134a | MBP/HBP |
GS | GS26MFX | 1 | 26.3 | 1164W | 220-240V 50HZ | R134a | MBP/HBP |
GS | GC34MFX | 1 | 33.8 | 151W | 220-240V 50HZ | R134a | MBP/HBP |
NL | NL10FT | 3/8 | 10.1 | 284W | 220-240V 50HZ | R134a | LBP/MBP |
SC | SC21FTX | 3/4 | 20.95 | 567W | 220-240V 50HZ | R134a | LBP/MBP |
BD | BD35F | _ | _ | 51W | 12V DC | R134a | |
BD | BD50F | _ | _ | 72W | 12V DC | R134a |
